Page 10 (20)
Press the menu-button once to exit the Information view.
Event Log
To access the Event Log – Select EVENT LOG in the menu.
All alarms and most events are time stamped with the running hour
meter, and stored internally. The log cannot be erased by the user.
The logbook stores ~500 events. After the ~500
th
event, the
oldest event will disappear.
The last configuration (or change of configuration) will not be
erased.
To view the log, press the menu-button. For button explanation,
see page 14.
View the log as you read a logbook: The last occurrence is at the
bottom of the screen.
To view earlier (older) events, press the Up arrow () and to
view newer events, press the Down arrow ().
Press the menu-button once to exit the Event Log.
CAN Status/Restart
Used for debugging only.
Diagnostic Display
Diagnostics is displayed according to SAE J1939-71. A complete list of
all diagnostic messages is found on
www.sae.org.
All active diagnostics messages are shown in the Diagnostic Display
view. The digit code for SPN and FMI’s are shown together with the
belonging Diagnostic Message Text. When no SPN and FMI’s are active,
the screen is empty.
DIAGNOSTIC DISPLAY 1 FAULT
