Page 9 (20)
The toggling asterisk and plus sign (*/+) in front of a line
means the alarm is activated and not yet acknowledged.
Note: In the Alarm list view, pressing the Acknowledge button will
acknowledge all the alarms simultaneously.
Press the menu-button once to exit the Alarm List.
Information
To access the Information view – select INFORMATION in the menu.
The top half of the picture displays static user information, such as
project no. engine serial no. generator serial no. service telephone
number, etc.
This information is entered using the configuration tool Rudolf.
Information view
The bottom half of the picture displays various timers and counters.
The Operation Mode is listed, along with the following counters:
Engine hours (0-65535 hours)
Previous running hours (“trip” counter)
Engine starts (0-65535 successful starts)
Start failures (0-65535 start failures)
Communication msg. Counter
Fuel consumption/ Average consumption – if chosen in the
Rudolf configuration tool.
The current software and hardware version is displayed at the bottom
line.
All events are time stamped with running hours, with 0.01 hours
resolution. 0.01 hours equals 36 seconds.
After two minutes in the INFO view, the control unit automatically
returns to the Instrument view.
Static project-
related information
