Auto Meter RC-300 User Manual

6
15
AUTO METER�
RC-300�
BATTERY TESTER�
READY TO CONNECT
R
C
-
3
0
0
Reserve Capacity Battery Tester
Reserve Capacity
Battery
>BATTERY TEST
REVIEW PRINT
VOLTMETER
DATABASE
Press ‘Y” to open menu. Select
Battery Test by pressing ‘Y’
Enter the approximate battery
temperature in degrees Fahrenheit or
Celsius then press (Y Enter).
Note: Go to the setup to change
temperature scale to Celsius. The
temperature request only appears
once for each battery tested.
1
HOOK UP
SETUP
Press the On/Off button: Connect the clamps to the battery.
Scroll Down to Setup, Select setup by pressing 'Y'.
Select the temperature in Fahrenheit
or Centigrade.
>SET TEMPERATURE
SCALE: F
USE +/-
'Y' TO SELECT
>SET LANGUAGE:
ENGLISH
USE +/-
'Y' TO SELECT
Choose between English, Spanish,
or French using the + and - keys to
change the language. Press 'Y' to
select.
VOLT METER
DOWNLOAD
>SETUP
ABOUT
>SET DEFAULT AH
AS: 30.0
USE +/-
'Y' TO SELECT
DO YOU WANT TO
DISPLAY MEASURED
BATTERY CAPACITY
'N' OR 'Y'
You can also select the default rating
to be the last entered AH value or a
particular amount such as 30.0 AH.
If 'Y' is chosen, the measured battery
capacity will be displayed on the
battery test result screen and print out.
If 'N' is chosen no measured battery
capacity will be displayed or printed.
AUTO METER
RC-300
BATTERY TESTER
'Y' FOR MENU
>ENTER BATTERY
TEMP: 70F
USE +/-
'Y' TO CONTINUE
>CONNECT CLAMPS
TO BATTERY
RED + BLACK-
'N' TO CANCEL
CONNECTION ERRORS
If the clamps are reversed the
Reversed Connection screen will ash.
If one or both of the clamps are
not in complete contact CHECK
CONNECTIONS! will ash.
If no clamps or only one clamp
is connected the following
will be displayed:
