14
7
Pressing 'Y'' or 'N' will
return to the main menu.
Let battery cool before
testing.
If the battery has an AH
rating and is not in the
database select AH rating
using the + and - keys
and the 'Y' key to select.
If the battery has a database
entry, select the database
rating option by using the +
and - keys and use the 'Y' key
to select database.
Use the + and - keys to
enter the rated AH. Press
'Y' to continue.
Use the + and - keys to select
the battery from the database.
Press 'Y' to continue
2
If the battery temperature is above 180°F the battery is too
hot to test. The following screens will appear.
Any battery whose ratio is in between the Good Cutoff and Bad Cutoff is
graded as Near End of Life if that feature is active.
BATTERY TEST
THE BATTERY
IS TOO HOT TO
TEST SAFELY
'Y' TO CONTINUE
THE BATTERY
NEEDS TO COOL
BEFORE TESTING
'Y' TO CONTINUE
BATTERY RATING
AH RATING
USE +/-
'Y' TO CONTINUE
ENTER RATED AH
25.00 USE +/-
12.68V
'Y' TO CONTINUE
BATTERY RATING
DATABASE
USE +/-
'Y' TO CONTINUE
ENTER DATABASE
BATTERY #1
CF=0.67 AH=27.0
'Y' TO CONTINUE
DATABASE (cont.)
Enter the Bad Cutoff
Limit. Any ratio below
this limit is graded a
Bad Battery.
Enter the reference battery's
temperature.
The battery will be tested
to determine the Correction
Factor.
The battery's information
is stored in the next open
database index. If the database
is full you will need to delete a
battery to make room for a new
battery.
Use the + and - Keys to select
the battery index to delete.
Press 'Y' to delete the battery.
To delete a battery from the
database select Delete Battery.
NOTE: The Bad Cutoff MUST
BE below the Good Cutoff.
ENTER BAD
CUTOFF 65%
USE +/-
'Y' TO CONTINUE
ENTER BATTERY
TEMP: 70F.
USE +/-
'Y' TO CONTINUE
BATTERY ADDED
TO DATABASE AS
BATTERY #7
DATABASE MENU
REVIEW DATABASE
ADD BATTERY
>DELETE BATTERY
ENTER DATABASE
BATTERY #1
USE +/-
'Y' TO CONTINUE
BATTERY DELETED
FROM DATABASE
TESTING BATTERY
PLEASE WAIT...
