ENGLISH
29/78
Method for connection directly to the vehicle’s
battery:
1
Identify the battery’s positive terminal (+) and
negative terminal (-).
2
Connect the bridle’s (G.1) power wiring eyelets to
the relative terminals (red wire + / black wire -).
It is advisable to leave the bridle (G.1)
permanently connected to the battery.
3
When needed, connect the extension cable (G.2)
to the bridle (G.1) and to “U-GO”.
The user is free to choose the extension cable’s
placement (G.2) according to his requirements.
6.4 - TUBING
For operation, it is necessary to connect the tubing between “U-GO” and its various components.
“U-GO”‘s flexible tubing (B) can extend and collapse in order to better suit the user’s needs; this allows to place
“U-GO” in the most suitable position.
In placing the tubing it is, however, useful to follow a few simple suggestions in order to obtain the best
performance.
The tubing can be extended or shortened by simply polling them from the ends with your hands; they can also be
curved so as to achieve the best path.
In order to secure the tubing to “U-GO” and to its
other components (for example to the snorkel) it
is necessary to place the entrance nozzles (C) to
the ends:
- extend the tubing tip for a length equal to the
height of the entrance nozzle;
- fit the entrance nozzle to the tubing tip rotating it
counter-clockwise (as if you were screwing it on);
- stop when the tubing tip reaches the nozzle’s
edge.
