Operating the AUTOLIFT3000
Positioning of the lifting device
Slide the lifting device in starting position
under the vehicle so that the gearboxes
face the engine. Align and center the lift
under the vehicle on the longitudinal axis.
Position the support platforms
symmetrically under the vehicle sill
braces. Check that the platforms do not
touch any fragile parts of the vehicle. If
necessary, beam pads can be used to
dene the height.
To lift the front of the vehicle, position the
lifting device so that the gearboxes
almost touch the front wheels (for
vehicles with a front engine). To lift the
rear of the vehicle, move the lifting device
a few centimetres backwards so that the
centre of gravity moves forward.
Lifting
Carefully tighten the drill adapter in the
drill. Then insert it into the gearbox outlet.
Make sure that the drill is set to rst
speed and the impact is switched o.
Start the drill in the right-hand direction
(clockwise) and hold it rmly. Always
follow the symbols on the stickers
located near the gearboxes which
indicate the rotation of the drill. Always
make sure that the drill head rotates in
the desired direction.
Lift the vehicle slowly and make sure that
no deformation is occurring (if you
suspect that something like this may be
happening, lower the vehicle back and
adjust its position on the lifting device).
Never exceed the maximum lift height
marked with red STOP tape!
After reaching the required or maximum
height, secure the lift with the safety pin.
Before starting the work, make sure that
the vehicle is stable on the lift and cannot
ip or slide. Always secure the vehicle
with a car stand support.
Make sure you are lifting an unibody vehicle! The AUTOLIFT3000 is not
designed for lifting body on frame vehicles!
Never exceed the maximum lift height marked with red STOP tape!
Positioning of the lifting device for tilting the vehicle
To tilt the vehicle, it is necessary to lift it
at its centre of gravity. For front-engined
vehicles, position the lifting device so that
the gearboxes almost touch the front
wheels; for a family minivan, leave a
distance of 7-10 cm; for rear-wheel drive
vehicles, leave a distance of approx.
25-30 cm between the gearboxes and the
front wheels. The tilting of the vehicle is
done manually.
TIP for fast nding car's point of gravity:
Place the lifting device about 10 cm from
the wheels of the engine axle. Raise the
vehicle to a position where one of the
axles of the vehicle is lightened to a
height of approximately 10 cm. At this
point try to tilt the vehicle. If tilting is
dicult or not possible at all, return the
lifting device to its initial position. Move it
closer to the axle of the car that has
remained on the ground. This step should
lighten the axle and you should be closer
to the centre of gravity. Repeat the
procedure until tilting of the car becomes
easy.
Tilting
In case of tilting, remove the car stand
support. Take the vehicle by its solid part
to avoid any damage. Always hold the
vehicle when tilting so that no sudden
movements can occur. Always consider
the height of the ceiling when tilting the
vehicle. Ensure that the tilting is smooth
and always restrained by the operating
person. When the tilting is nished, re-
secure the vehicle with the car stand
support.
