Connect the two AS 1613 circuit boards to each other using cable W15
Connect the two AS 1613 circuit boards to each other using cable W14
See wiring diagrams
1FL01.001A  1FL01.002
W15
RIGHT Gate
CN3 (AS1613)
LEFT Gate
CN3 (AS1613)
See wiring diagrams
1FL01.001A  1FL01.002
W14
CN1 (AS1613)
CN2 (AS1613)
RIGHT Gate
LEFT Gate
