Automatic Technology DOMINATOR ShedMaster GDO-8V3 - Specifications

6
GDO-8V3 Shed Master Instruction Manual
2. Specifications
Technical Specifications DOMINATOR ShedMaster
®
GDO-8V3
Power supply 120Va.c. 60Hz
Maximum door opening
Width:
Height:
Maximum Door Weight:
Door Area:
Door must be well balanced and able to be operated by
hand, as per warranty conditions and standard
AS/NZS 4505:2012
5500mm
2700mm
100kg
16.5m
2
Minimum sideroom 40mm
Lift Force 450N
Nominal force 120N (12kg)
Receiver type Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Receiver code storage capacity 8 X Triocode
TM
128
4-button Transmitters
Coding System TrioCode
TM
128 Type
Coding type Code Hopping
Number of code combinations Over 100 billion random codes
Transmitter battery CR2032 (3 Volts)
Courtesy light Light Module (Optional)
Network connectivity Not Available
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn intermittently trigger the safety obstruction detection system.
