DETERMINE THE DOOR TYPE
Step 4
Determine which type of garage door you have as illustrat-
ed below. (Fig. 9 - 11).
l For a sectional (panel) door on tracks (Fig. 9) proceed with
the installation from Step 5.
l For a one piece door on tracks (Fig. 10) proceed with the
installation from Step 5.
l For a one piece door without tracks (on springs) (Fig. 11)
proceed with the installation from Step 9.page 13
11
one piece door
without track
FIG. 11
FIG. 10
FIG. 9
