1) P.E. SHUNT
2) 24V POWER INPUT CONNECTOR
3) 10 AMP FUSE
4) SBY-3 BATTERY BACK UP CONNECTOR
5) MOTOR CONNECTOR
6) OPERATE (YELLOW) BUTTON
7) PLUS (+) (GREEN) BUTTON
8) PG-3 PROGRAMMER CONNECTOR
9) COURTESY LIGHT MODULE
10) FORCE MARGIN BUTTON
11) OPEN LIMIT LED
12) AUTO CLOSE TIME BUTTON
13) CLOSE LIMIT LED
14) MINUS ( - ) (RED) BUTTON
15) STATUS LED
16) DOOR CODE (BLUE) BUTTON
17) CODE SET LED
18) LIGHT CODE BUTTON
19) EASY ACCESS TRANSMITTER
20) SET (ORANGE) BUTTON
21) PE, O/S/C CONNECTOR
20
16
14
15
19
17
13
12
18
2
3
4
5
6
7
8
9
10
11
1
OPERATING CONTROLS
6
FIG. 1
21
