DPM1 User Manual, 1st Edition
User Manual - DPM1 Series Panel Meters
11
Programming numerical values
When the parameter is a numerical value, the display will show the first of the digit to be
programmed blinking.
Digit selecting: Press repeatedly the SHIFT key to shift from left to right over all the display
digits.
Changing the digit value: Press repeatedly the UP key to increase the value of blinking digit
until it has the desired value.
The minus sign is programmed depending on the variable type. A variable that represents the
value of an input will be able to take a value in the range -1999 to 9999, without taking into
account the decimal point. When a digit is selected it shows values from (0) to (9), and then
(-1), (-), and comes back to show values from 0 to 9. A variable that represents a display value
will be able to take a value in the range -1999 to 9999, without taking into account the decimal
point.
Completion of each submenu routine returns the meter to Pro mode. To save data entered or
changed during configuration press the ENTER key while in Pro mode. Stor will be displayed
for a few seconds while all of the configuration data is stored in memory. The meter will then
return to RUN mode.
