● BF4R / BF4G
● BF4R-E / BF4G-E
● BF4RP / BF4GP
● BF4R-R / BF4G-R
(brown) +V
(black) Control output
(white) Self-diagnosis output
(blue) 0V
Load
Load
12-24VDC
+
-
(brown) +V
(black) Control output
(white) Self-diagnosis output
(blue) 0V
Load
Load
(pink) External synchronization input
(orange)
Emission disable input
12-24VDC
+
-
(black) Control output
(white) Self-diagnosis output
(blue) 0V
(brown) +V
Load
Load
12-24VDC
+
-
(brown) +V
(black) Control output
(white) Self-diagnosis output
(blue) 0V
Load
Load
(pink) ON input of remote sensitivity setting
(orange)
OFF input of remote sensitivity setting
12-24VDC
+
-
Connections
Dimensions
12
2-Ø2.4
87.3
32.8
32.8
12
2-Ø2.4
87.3
32.8
62
36.5
Ø4, 2m
16.4
3
4
14
35mm DIN rail
useable
26.9
65.3
38
9
27
14
2
35
8.5
4
12
1
16
R1.6
2
● Connect the bracket
● Bracket
(unit: mm)
