Autonics BX Series User Manual

A-54
BX Series
Connections
Through-beam type
● BX15M-TFR1
12-24VDC
OUT2(PNP)
OUT1(NPN)
STAB(NPN)
Sensing
target
12-24VDC
OUT2(PNP)
OUT1(NPN)
STAB(NPN)
Sensing
target
Mirror
45
50
60
Terminal No.
Cover
Waterproof
rubber
Wire holder
Washer
①
④
②
⑤
③
ø6 to 10mm
Power
24-240VAC
24-240VDC
Sensing
target
Mirror
N.O.
COM
N.C.
Power
24-240VAC
24-240VDC
Sensing
target
N.O.
COM
N.C.
● BX15M-TDT1● BX15M-TFR2
BX15M-TFR2-T
● BX15M-TDT2
BX15M-TDT2-T
Retroreflective type / Retroreflective type with polarizing filter
Diffuse reflective type
Cable
● BX5M-MFR, BX5M-MFR-T(Standard type)
● BX3M-PFR, BX3M-PFR-T(Built-in polarizing filter)
● BX5M-MDT, BX5M-MDT-T(Standard type)
● BX3M-PDT, BX3M-PDT-T(Built-in polarizing filter)
● BX700-DDT, BX700-DDT-T● BX700-DFR, BX700-DFR-T
(unit: mm)
※
To connect the wires on the terminal, follow as above gures.
※
Select the round wire with the size of ø6 to 10mm for the waterproof and tighten the cable holder by torque of 1.0 to 1.5N
.
m.
※
To connect the wires on the terminal, tighten screws by torque of 0.8N
.
m.
●Crimp terminal size
Max. 19
Max. 19
Max. 10
Max. 10
Max. 7
Max. 7
Max. 7
Max. 7
Min. 3.6
Min. 3.6
Power Power
24-240VAC
24-240VDC
24-240VAC
24-240VDC
Sensing
target
N.O.
COM
N.C.
N
.
C(Not connected)
N
.
C
(Not connected)
12-24VDC
12-24VDC
OUT2(PNP)
OUT1(NPN)
STAB(NPN)
Sensing
target
N
.
C(Not connected)
N
.
C
(Not connected)
