나 5 Guide For Connection
© Copyright Reserved Autonics Co., Ltd. 35
5.2.3 Output connection
(1) Contact output
Select the load which capacity is not over contact capacity.
(2) Solid state output
For solid state output, select load power and load not to be over (max. 30VDC, 100mA),
switching capacity.
Do not supply reverse polarity voltage.
※1: For using inductive load (relay, etc), connect surge absorber (diode, varistor, etc) at the both
ends of load.
