Output Operation Mode (Timer)
Retained output
One-shot output (0.01 to 99.99 sec)
Retained output
One-shot output
※
Power RESET: There is no memory protection. (resets the display value when power is off)
※
Power Hold: There is memory protection.
(memorizes the display value at the moment of power off, indicates the memorized display value when power is resupplied.)
Output
mode
Time chart
Operation
FLK
[
FLK
]
Flicker (Power RESET)
RESET
POWER
INA(START)
INH(INHIBIT)
Setting time
Setting time
Setting time
Setting time
T.on
T.on
T.off
T.off
0
0
UP
Display
Down
OUT2(OUT)
T.off T.off T.offT.offT.on
T.on T.onT.on
Ta Tb
1) Time starts when INA signal turns ON.
2) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
3) Control output operates as retained
output, output turnsoff for the T.off
time and turns off for the T.off time
and turns on for the T.on time
repeatedly.
Ta+Tb = T.off
4) The T.on time and T.off time must be
set individually.
5) In case of using the contact output,
min. setting time must be set over
100ms.
FLK.1
[
FLk1
]
Flicker 1 (Power Reset)
1) Time starts when INA signal turns ON.
2) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
3) Control output operates as retained
(Hold) output.
4) In case of using the contact output,
min. setting time must be set over
100ms.
RESET
Setting time
Setting time
POWER
Retained (Hold) output
INA(START)
INH(INHIBIT)
0
0
Up
Display
Down
OUT2(OUT)
RESET
Setting time
Setting time
POWER
One-shot output
INA(START)
INH(INHIBIT)
0
0
Up
Display
Down
OUT2(OUT)
t t t
1) Time starts when INA signal turns ON.
2) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
3) Control output operates as one-shot
output.
4) In case of using the contact output,
min. setting time must be set over
100ms.
T.off T.offT.on
POWER
INA
OUT2
(OUT)
T: Setting time
POWER
T T T
INA
OUT2
(OUT)
T: Setting time
POWER
T T T
INA
OUT2
(OUT)
