J-28
CX Series
Output Operation Mode (Timer)
Retained output
One-shot output (0.01 to 99.99 sec)
Retained output
One-shot output
Output
mode
Time chart
Operation
FLK.2
[
FLk2
]
Flicker 2 (Power Hold)
RESET
Setting time
Setting time
POWER
Retained (Hold) output
INA(START)
INH(INHIBIT)
0
0
Up
Display
Down
OUT2(OUT)
1) Time starts when INA signal turns ON
and the display value at the moment
when power is off is memorized.
2) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
3) Control output operates as retained
(Hold) output.
4) Control output will be reversed when
it reaches to setting time.
(at the initial start, OUT2 control
output is OFF).
5) In case of using the contact output,
min. setting time must be set over
100ms.
RESET
Setting time
Setting time
POWER
One-shot output
INA(START)
INH(INHIBIT)
0
0
Up
Display
Down
OUT2(OUT)
t t t t
a t-a
1) Time starts when INA signal turns ON
and the display value at the moment
when power is off is memorized.
2) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
3) Control output operates as one-shot
output.
4) In case of using the contact output,
min. setting time must be set over
100ms.
INT
[
INT
]
Interval (Power RESET)
1) Control output turns ON and time
starts when INA signal turns ON.
2) When INA signal is OFF, time is reset.
3) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
4) When it reaches setting time,
it is auto reset.
5) Control output is ON when the time is
progressing.
RESET
Setting time
Setting time
POWER
INA(START)
INH(INHIBIT)
0
0
Up
Display
Down
OUT2(OUT)
INT.1
[
INt1
]
Interval 1 (Power RESET)
1) Control output turns ON and time
starts when INA signal turnsn ON.
2) When INA signal is ON
: Power ON Time Start is operated.
RESET OFF Time Start is operated.
3) When it reaches setting time,
it is auto reset.
4) Control output is ON when the time is
progressing.
5) Time is ignored while time is
progressing.
RESET
Setting time
Setting time
POWER
INA(START)
INH(INHIBIT)
0
0
Up
Display
Down
OUT2(OUT)
T: Setting time
POWER
T T
INA
OUT2
(OUT)
T: Setting time
POWER
T
INA
OUT2
(OUT)
T: Setting time
T
Hold
T-c c T
POWER
INA
OUT2
(OUT)
T: Setting time
POWER
T
Hold
T-c c T
INA
OUT2
(OUT)
※
Power RESET: There is no memory protection. (resets the display value when power is off)
※
Power Hold: There is memory protection.
(memorizes the display value at the moment of power off, indicates the memorized display value when power is resupplied.)
