Autonics FXY Series Instruction Manual

M-68
FXY Series
Connections
● FX Y-I4 ● FX Y-I2
※
INHIBIT: In case of timer mode, this terminal is for time hold.
(voltage input (PNP): connect with 12VDC, no-voltage input (NPN): connect with 0VDC)
Dimensions
(unit: mm)
Counting Method
NPN output type proximity sensor
: When the sensor is changed from OFF to ON, it counts.
PNP output type proximity sensor
: When the sensor is changed from ON to OFF, it counts.
Be careful to select sensor because the counting method of NPN output type sensor is di󰀨erent from PNP
output type sensor.
Target
Target
0 0
1
1
2
2
PR18-5DN
Target
PR18-5DP
Target
Have
None
Have
None
ON
OFF
ON
OFF
Counting number Counting number
LED
LED
1 2 3 4 6 7
CP1
※
(INHIBIT) PNP NPN
CP2 12VDC
50mA
0VDC RESET
SOURCE:
100-240VAC
50/60Hz 3.8VA
5
SOURCE
: ● 24VAC 50/60Hz 2.8VA
● 24-48VDC 1.8W
PNP NPN
1 2 3 4 6 7
CP1
※
(INHIBIT)
CP2 12VDC
50mA
0VDC RESET
5
Bracket Panel cut-out
72
776
36
30
Min. 91
Min. 40
68
31.5
+0.7
0
+0.5
0
9
4
60
12
14.5
