42
产品结构
滚花螺杆
排油阀
玻璃测试量筒
控制面板
1
3
2
4
压力表
电源插口
电源开关
脉冲信号线
5
7
6
8
收纳抽屉
9
供油管12 检测液视窗13
超声波清洗槽 清洗液排油阀10 11
整机结构
1
2
3
4
5
9
6
7
8
10
11
13
12
