Page - 7
Flow Bypass Kit (Optional)
The ChlorSync
®
models are compatible with an optional flow bypass kit. The #STK0240
assembly allows the water flow rate to be slowed through the cell, while permitting the pump to
continue to circulate water to-and-from the pool/spa at full flow rates. The reduced water flow
through the cell results in a more efficient "Super-Chlorination” effect, resulting in improved
overall sanitization.
This bypass kit should be plumbed directly inline with the cell. See installation instructions in the
Installations Steps section of this manual.
ChlorSync
®
Flow Bypass Kit
Figure 3
Patented Temperature Compensation
The ChlorSync
®
uses the temperature sensor to determine water temperature. This
measurement is required for the temperature compensation feature to automatically adjust
chlorine output as water temperature varies.
The water temperature sensor works in conjunction with the purifier % feature to automatically
adjust chlorine output based upon changes in water temperature. Less chlorine is needed in
cold water, so chlorine output is automatically reduced as water temperature drops (avoiding
excess chlorine production). Conversely, more chlorine is needed in warmer water, and
production is automatically adjusted higher as water temperature increases.
As the water temperature falls below 65°F (18°C), the controller will automatically reduce the
purifier % and will reduce the maximum % that can be selected. This feature prevents the
controller from generating excessive chlorine in cold water where it is not needed and prevents
premature cell failure.
Note: The unit will display the original user specified setting.
