Autostacker™ Parking Lift 63 P/N 5900248 — Rev. B — May 2021
Optional MPU Enclosure
The optional MPU Enclosure (PN 5215860) protects the Power Unit from the outdoor elements.
Tip We recommend that you first situate the Master Power Unit inside the Base, then
assemble the Enclosure around it.
⚠ CAUTION The Master Power Unit is heavy; use caution when moving it. You must use a
Forklift, Shop Crane, or other lifting device when moving it to its location.
The following drawing shows the components that make up the MPU Enclosure.
To assemble the MPU Enclosure:
1. Locate the 56 Spring Nuts and Socket Head Cap Screws.
2. Assemble the components near where you are going to install it.
Note: Some components look the same, but are
not
interchangeable.
3. Place the Top Section above the Base Section.
