3.1 Typical Installation Drawings
Figure 3.3 Magnum Cv and Magnum IT, Single Tank Softener Units with 962 Electronic Control
Inlet Valve
Drain
962 Control
1.5” Riser Tube
Hub & Lateral
Brine Tank
Brine Line
Turbine (standard
with 962 Control)
Outlet Valve
Manual Bypass Valve
Drain Line Flow Control
Note: Support Inlet and
Outlet Piping
Adequately.
(Required)
Magnum Cv
Magnum IT
