Autotrol Magnum Cv 962M - 952,952 F, and 952 QC Impulse Controls

67
12.3 Impulse Controls
Figure 12.5 Magnum 952
Figure 12.6 Magnum 952F
Figure 12.7 Magnum 952QC
Magnum 952
Magnum 952F
Table 12.5 952 Impulse Control 50 Hz Configurations
Part Number Description
1046854 Impulse Control/952 Softener/24 VAC/50 Hz
1046855 Impulse Control/952F Filter/24 VAC/50 Hz
1046856 Impulse Control/952QC Softener/24 VAC/50 Hz - 7 foot (2.1 m) Cable
1046857 Impulse Control/952QC Softener/24 VAC/50 Hz - 14 foot (4.2 m) Cable
1046858 Impulse Control/952QC Softener/24 VAC/50 Hz - 21 foot (6.3 m) Cable
Magnum 952QC
