AUX ALCA-H**R1AA User Manual

AUX Light Commercial Air Conditioners T1,50Hz, R410a,ON/OFF
56
16
直流电机 FP90A-ZL(长短轴)
Moter
1
17
ALCe-H24B4/C5 左挂架
Left suspend plate
1
18
ALCe-H24B4/C5 左侧板组件
Left side panel assembly
1
19
ALCe-H24A4/R1DCC5-B6 背板
组件
Chassis welding assembly
1
20
联轴器 φ15
Motor coupling
1
21
加长轴 φ15×565
Motor lengthen axes
1
22
ALCe-H24B4/C5 右侧板组件
Right side panel assembly
1
23
ALCe-H24B4/C5 右挂架
Right suspend plate
1
24
ALCe-H24B4/C5 右盖板
The Right side covers
1
25
ALCe-H24B4/C5 右泡沫(开模)
Right foam
1
26.1
CJ 控制板
DCZ-OXNX-SN1T1(18-60)K-SY
E
PCB board
1
26.2
CJ 控制板
DCZ-OXNX-SNPOWER-C-SYE
PCB board
1
27
DR-120N/DC5-A 电控盒
The electronic control box
1
28
ALCe-H24B4/C5 中滤网
Filter In the center
1
29
ALCe-H24B4/C5 中格栅
Air-inlet grill
1
30
ALCe-H24B4/C5 滤网
Air-inlet filter
2
31
ALCe-H24B4/C5 格栅
Air-inlet grill
2
32
ALCe-H24B4/C5 显示盒组件
Display board cover
1
33
(ROHS)步进电机
35BYJ46-QC50
Step motor
1
34
步进电机 35BYJ46-QC120
Step motor
1
