AUX ALCA-H**R1AA User Manual

AUX Light Commercial Air Conditioners T1,50Hz, R410a,ON/OFF
60
13
DR-140N/DC5-A 背板组件
Chassis welding assembly
4
14.1
CJ 控制板
DCZ-OXNX-SN1T1(18-60)K-
SYE
PCB board
1
14.2
CJ 控制板
DCZ-OXNX-SNPOWER-C-S
YE
PCB board
1
15
DR-120N/DC5-A 电控盒盖
The electronic control box
cover
1
16
ALCe-H42A5/C5 集水盘组件
Draining tray
1
17
ALCe-H42A5/C5 电机固定板
Volute fixing board
1
18
橡胶轴承 GR-50D/DC2
Rubber bearings
1
19
GR-50D/DC2 橡胶轴承压板
Bearing top cover
1
20
上涡壳 ALCe-H24B4/C5(白
色)
Volute assembly
1
21
加长轴 φ15×565
Motor lengthen axes
1
22
联轴器 φ15
Motor coupling
1
23
直流电机 FP150B-ZL
Motor
1
24
风轮 φ145×190×φ15(白色)
Fan
1
25
下涡壳 ALCe-H24B4/C5(白
色)
Volute assembly
1
26
ALCe-H42A5/C5 集水盘固定
板组件
Draining tray fixed plate
21
27
ALCe-H24B4/C5 集水盘压板
Draining tray plate
1
28
ALCe-H24B4/C5 右侧板组件
Right side panel assembly
1
29
ALCe-H24B4/C5 右挂架
Right suspend plate
1
30
ALCe-H24B4/C5 右盖板
The Right side covers
1
31
ALCe-H24B4/C5 中格栅
Air-inlet grill
1
32
ALCe-H24B4/C5 中滤网
Filter In the center
1
33
ALCe-H24B4/C5 右泡沫(开
模)
Right foam
1
34
步进电机 35BYJ46-QC120
Step motor
1
35
ALCe-H24B4/C5 显示盒组件
Display board cover
2
35
ALCe-H24B4/C5 右装饰板组
件
Right plate assembly
2
36
(ROHS)步进电机
35BYJ46-QC50
Step motor
1
