AUX ALCA-H**R1AA User Manual

AUX-Light CAC 50Hz R410A Universal outdoor unit
65
Model
Indoor Unit
ALMD-H36/5R1D
ALMD-H48/5R1D
ALMD-H60/5R1D
Outdoor Unit
AL-H36/5R1D(U)
AL-H48/5R1D(U)
AL-H60/5R1D(U)
Factory Model
Indoor Unit
ALHi-H36A5/R1S3-
B7
ALHi-H48A5/R1S
3-B7
ALHi-H60A5/R1S
3-B7
Outdoor Unit
AL-H36A5/R1(T)-B7
AL-H48A5/R1(T)-
B7
AL-H60A5/R1(T)-
B7
Code
Indoor Unit
16113022000044
16113022000045
16113022000046
Outdoor Unit
16107022000020
16107022000022
16107022000023
Power Supply
V~,Hz,Ph
380~415,50,3
380~415,50,3
Capacity
Cooling
Btu/h
36000
48000
60000
kW
10.6
14.0
17.6
Heating
Btu/h
40000
53000
63500
kW
11.7
15.5
18.5
Electric Data
Rated Cooling Power Input
kW
3.73
4.87
5.71
Rated Heating Power Input
kW
3.50
5.13
6.00
Rated Cooling Current
A
6.69
8.88
10.42
Rated Heating Current
A
6.28
9.33
10.88
Performance
EER
W/W
2.84
2.87
3.08
COP
W/W
3.34
3.02
3.08
Indoor Fan
Fotor
Model
YSK180-4
YSK180-4
YSK180-4
Brand
Kangbao
Kangbao
Kangbao
Output Power x Fan
Quantity
W
180
180
180
Capacitor
uF
6
6
6
Speed (Hi/Mi/Lo)
r/min
1200/1120/1060
1200/1120/1060
1200/1120/1060
Indoor Coil
Number Of Rows
3
3
3
Tube Pitch(a)x Row
Pitch(b)
mm
20.5×12.7
20.5×12.7
20.5×12.7
Fin Spacing
mm
1.6
1.6
1.6
Fin Material
Hydrophilic aluminum fin
Tube Outside Dia.and
Material
mm
625×369×38.1
φ7， Inner
grooved
φ7， Inner
grooved
Coil Length x Height x
Width
mm
9.87
985×369×38.1
985×369×38.1
Heat Exchanging Area
m
2
2000/1600/1400
15.56
15.56
Indoor Unit
Indoor Air Flow (Hi/Mi/Lo)
m
3
/h
50/47/41
2400/2000/1600
2800/2240/1960
Noise Level(Hi/Mi/Lo)
dB(A)
50/80
53/50/44
53/50/44
External Static Pressure
Pa
890×785×290
50/80
50/80
Net Dimension (W*H*D)
mm
1100×870×360
1250×785×290
1250×785×290
Packing Dimension
(W*H*D)
mm
1100×870×360
1460×870×360
1460×870×360
Net Weight
kg
36
52
52
