AUX ALCA-H**R1AA User Manual

AUX-Light CAC 50Hz R410A Universal outdoor unit
66
Gross Weight
kg
42
59
59
Refrigerant
Pipe
Liquid Side
mm
9.52
9.52
9.52
Gas Side
mm
15.88
19.05
19.05
Max. Refrigerant Pipe
Length
m
50
50
50
Max. Level Difference
m
30
30
30
Setting Temperature Range
°C
16~32
16~32
16~32
Ambient Temperature
Range
Cooling
°C
-15~49
-15~49
-15~49
Heating
°C
-15~24
-15~24
-15~24
Application Area
m
2
42-70
42-70
64-107
Connection Wiring
Power Wiring( Indoor)
mm
2
3×1mm
3
3×1mm
3
3×1mm
3
Power Wiring( Outdoor)
mm
2
5×4mm
3
5×4mm
3
5×4mm
3
Signal Wiring
mm
2
2×1mm
2
2×1mm
2
2×1mm
2
Wireless Remote Controller
XK-02
XK-02
XK-02
Stufing Quantity
20/40/40H
Set
35/72/82
21/44/47
21/44/47
Note:
1. Working condition of the cooling capacity measured: Indoor temperature 27°C DB, 19°C WB;Outdoor
35°C DB, 24°C WB;
2. Working condition of the heating capacity measured: Indoor temperature 20°C DB, 19°C WB;Outdoor
7°C DB, 6°C WB;
3. Parameters above are all measured when the connecting pipe is 5 meters.
4. Parameters above may be modified as product improvement. We keep the right to change the product
specifications without prior notice, please take the parameters listed on the nameplate as criterion.

AUX ALCA-H**R1AA Specifications

General

Brand	AUX
Model	ALCA-H**R1AA
Category	Air Conditioner
Language	English
