AUX AMWM-H18/4R3F - Page 54

AUX DC Inverter Free Match 50HZ R32
54
3.2 18K
Model
Indoor
AMCF-H18/4R3A
Capacity
Cooling
Btu/h
18080(8530-19107)
kW
5.3(2.50-5.6)
Heating
Btu/h
19790(10340-24000)
kW
5.8(3.03-7.03)
Electric Data
Power Supply
V~,Hz,Ph
220~240,50,1
Cooling Power Input
W
80(20-125)
Heating Power Input
W
80(20-125)
Indoor Fan Motor
Model
FP40A-ZL
Output Power
W
40
Capacitor
uF
/
Speed (Hi/Mi/Lo)
r/min
1300/1100/1000
Indoor Coil
a. Number Of Row
3
b. Tube Pitch(a)x Row
Pitch(b)
mm 20.5x 12.7
c. Fin Pitch
mm
1.6
d. Fin Material
Hydrophilic aluminum fin
e. Tube Outside Dia.And
Material
mm
φ7， Inner grooved
f. Coil Length x Height x
Width
mm 599x246x38.1
g. Heat Exchanging Area
m
2
6.32
Performance
Air Flow Volume
CFM
500/412/353
m
3
/h
850/700/600
Sound Pressure Noise Level
dB(A)
45/42/40
Sound Power Noise Level
dB(A)
59
Dimension
Net Dimension (W*D*H)
mm
929×660×205
Packing Dimension (W*D*H)
mm
1010×720×290
