AUX AMWM-H18/4R3F - Page 78

AUX DC Inverter Free Match 50HZ R32
78
1.2 F Type (07K,09K,12K,18K,24K)
Display receive panel
Step M otor
Step M otor
FU SE
3.15A 250V
PC B
F o rc e d S w it c h
T ra n sfo rm e r
A n io n
H ig h V o lt a g e
G enerator
E le c tro sta tic
D u ste r
Tem perature Sensor
To O utdoor Unit
Som e m odels have no content inside dashed fram e
M1 M2
M4
M3
16437010000447
Indoor Unit Electric C hart
L N C
L N P E C
B ro w
B lu e
Y /G
B la c k
N O TE : D o tte d lin e p a rt in th e fra m e m a y n o t b e u se d .
D C F a n M o to r
A C F a n M o to r
W IF I M o d u le
