AUX-DC inverter ARV outdoor unit individual series technical manual
125
Remarks:
○(dim), ●(on), ★(flash)
The power lamp or timing lamp only flashesonce for each failure, and then the running lamp will indicates the
error code according to specific failure.
For 4-way cassette unit, the panel has added digital display to show the error code.
2.2 Outdoor unit error code display
For outdoor units, the error code displays on the main PCB.
Outdoor unit control box
