AUX ANB66FVAMT - 3.5 Capacity Table

DC inverter ARV Individual Series technical manual
25
3.5Capacity Table
 Cooling Capacity table
ARV-H615/5R1B
Combination
(%)
Outdoor
Indoor temperature(°C)
Capacity
index
temp.
(°CDB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
130%
10
54.23
8.55
64.67
10.45
74.93
12.40
77.83
12.69
78.82
12.43
80.73
11.91
82.77
11.36
12
54.23
8.69
64.67
10.64
74.93
12.66
76.72
12.60
77.83
12.36
79.62
11.82
81.66
11.63
14
54.23
8.88
64.67
10.84
75.92
12.80
75.92
12.57
76.72
12.29
78.82
12.19
80.73
12.30
16
54.23
9.00
64.67
11.06
74.80
14.20
74.80
12.66
75.60
12.71
77.70
12.84
79.62
12.97
18
54.23
9.19
64.67
11.29
73.69
13.23
73.69
13.30
74.80
13.38
76.72
13.51
78.82
13.64
19
54.23
9.39
64.67
12.01
72.76
13.88
72.76
13.97
73.69
14.05
75.60
14.16
77.70
14.31
21
54.23
9.64
64.67
12.43
72.33
14.22
72.33
14.28
73.32
14.36
75.23
14.51
77.15
14.64
23
54.23
10.34
64.67
13.34
71.22
14.86
71.22
14.93
72.21
15.01
74.12
15.15
76.04
15.31
25
54.23
11.03
64.67
14.28
70.42
15.51
70.42
15.59
71.22
15.68
73.32
15.84
75.23
15.99
27
54.23
11.79
64.67
15.29
69.31
16.23
69.31
16.25
70.17
16.32
72.21
16.51
74.12
16.68
29
54.23
12.60
64.67
16.32
68.19
16.80
68.19
16.91
69.31
17.01
71.22
17.18
73.32
17.36
31
54.23
13.44
64.37
17.29
67.27
17.49
67.27
17.49
68.19
17.66
70.17
17.86
72.21
18.07
33
54.23
14.31
63.25
17.94
66.15
18.11
66.15
18.23
67.27
18.33
69.31
18.53
70.98
18.75
35
54.23
15.25
62.20
18.59
65.35
18.81
65.35
18.90
66.15
19.00
68.19
19.23
70.17
19.44
37
54.23
16.23
61.34
19.25
64.24
19.48
64.24
19.57
65.35
19.70
67.14
19.94
69.05
20.12
39
54.23
17.29
60.29
19.90
63.25
20.12
63.25
20.26
64.24
20.38
66.15
20.60
68.19
20.85
41
53.93
18.38
59.86
20.76
62.88
20.93
62.88
20.99
64.11
21.13
65.60
21.31
67.95
21.40
43
53.55
19.57
59.30
21.44
62.33
21.64
62.57
21.75
63.68
21.96
65.04
22.22
67.51
22.36
46
51.76
20.76
57.63
21.97
60.66
22.27
60.97
22.42
62.01
22.55
63.56
22.70
65.91
22.86
48
50.09
22.44
56.02
22.55
59.17
22.91
59.30
23.02
60.41
23.22
61.90
23.53
64.37
23.72
50
48.31
22.80
54.23
23.07
57.63
23.53
57.82
23.81
58.62
24.03
60.41
24.28
62.76
24.40
52
46.70
23.35
52.44
23.59
56.02
24.28
56.27
24.46
56.70
24.67
58.74
24.96
60.66
25.16
120%
10
50.09
7.80
59.54
9.53
69.31
11.32
74.12
12.23
77.70
12.77
79.50
12.27
81.10
11.79
12
50.09
7.95
59.54
9.69
69.31
11.52
74.12
12.47
76.59
12.69
78.39
12.21
80.05
11.71
14
50.09
8.08
59.54
9.89
69.31
11.77
74.12
12.71
75.49
12.60
77.40
12.13
79.19
12.21
16
50.09
8.25
59.54
10.08
69.31
11.99
73.69
12.80
74.55
12.64
76.35
12.77
78.07
12.86
18
50.09
8.39
59.54
10.28
69.31
12.40
72.64
13.23
73.45
13.28
75.23
13.42
77.15
13.55
19
50.09
8.58
59.54
10.70
69.31
13.34
71.65
13.88
72.64
13.94
74.37
14.06
76.04
14.17
21
50.09
8.64
59.54
11.06
69.31
13.81
70.98
14.22
71.90
14.27
73.88
14.38
75.60
14.55
23
50.09
9.25
59.54
11.86
69.31
14.79
70.17
14.84
70.98
14.92
72.76
15.04
74.55
15.18
25
50.09
9.86
59.54
12.69
68.19
15.43
69.05
15.49
69.86
15.54
71.90
15.71
73.69
14.42
27
50.09
10.54
59.54
13.56
67.27
16.05
68.19
16.16
69.05
16.23
70.85
16.38
72.64
16.53
29
50.09
11.23
59.54
14.47
66.15
16.71
67.14
16.80
67.95
16.88
69.74
17.05
71.65
17.22
31
50.09
11.99
59.54
15.45
65.35
17.38
66.15
17.46
67.14
17.55
68.75
19.16
70.54
17.90
33
50.09
12.77
59.54
16.51
64.24
18.03
65.04
18.12
66.03
18.20
67.70
18.40
69.43
18.59
