AUX ANB66FVAMT - Appendix; Relation between Temperature Sensor of Compressor and Resistance

AUX-DC inverter ARV outdoor unit individual series technical manual
131
6.Appendix
6.1 Relation between temperature sensor of compressor and resistance
R25=50KΩ±1%
B25/50=3950K ±1%
T [℃]
Rmin [KΩ]
Rnom [KΩ]
Rmax [KΩ]
-20
449.9
464.7
479.9
-19
425.7
439.5
453.6
-18
402.9
415.7
428.8
-17
381.5
393.4
405.6
-16
361.3
372.3
383.6
-15
342.2
352.5
363.0
-14
324.3
333.9
343.7
-13
307.5
316.4
325.5
-12
291.5
299.8
308.3
-11
276.6
284.3
292.2
-10
262.4
269.6
276.9
-9
249.0
255.7
262.5
-8
236.5
242.7
249.0
-7
224.5
230.3
236.2
-6
213.3
218.7
224.2
-5
202.7
207.7
212.8
-4
192.7
197.3
202.0
-3
183.2
187.5
191.9
-2
174.3
178.3
182.4
-1
165.8
169.5
173.3
0
157.7
161.2
164.7
1
150.2
153.4
156.7
2
142.9
145.9
148.9
3
136.1
138.9
141.7
4
129.7
132.3
134.93
5
123.6
126.0
128.4
6
117.8
120.0
122.3
7
112.2
114.3
116.4
8
107.1
109.0
111.0
9
102.1
103.9
105.7
10
97.42
99.08
100.8
11
92.97
94.51
96.06
12
88.74
90.17
91.61
13
84.73
86.05
87.38
14
80.92
82.14
83.37
15
77.29
78.42
79.56
16
73.84
74.89
75.95
17
70.57
71.54
72.51
18
67.46
68.35
69.25
19
64.49
65.32
66.15
