AUX ANB66FVAMT User Manual

AUX-DC inverter ARV outdoor unit individual series technical manual
11
Model
ARV-H780/5R1IB
ARV-H850/5R1IB
ARV-H900/5R1IB
Factory Model
AL-H280A5/MuR1D
IU（A）
AL-H300A5/MuR1D
IU（A）
AL-H320A5/MuR1D
IU（A）
Factory Code
16105022000090
16105022000089
16105022000089
Power Supply
V~,Hz,
Ph
380~415,50,3
380~415,50,3
380~415,50,3
Cooling
Capacity
kW
78.5
85.0
90.0
Input
kW
23.7
25.8
27.5
EER
W/W
3.3
3.3
3.3
Heating
Capacity
kW
87.5
95.0
100.0
Input
kW
22.0
24.4
26.3
COP
W/W
4.0
3.9
3.8
Max. Input Consumption
W
36.8
40.1
40.8
Max. Current
A
58.9
64.1
65.3
Connected
indoor units
Total capacity
50-130% of outdoor
unit capacity
50-130% of outdoor
unit capacity
50-130% of outdoor
unit capacity
Maximum quantity
46
50
53
DC
Inv.Compressor
Model
ANB66FVAMT
ANB78FVAMT
ANB78FVAMT
Quantity
2
2
2
Type
DC Inv
DC Inv
DC Inv
Brand
Mitsubishi
Mitsubishi
Mitsubishi
Capacity
W
21,500
25,400
25,400
Input
W
6,500
7,640
7,640
Power Supply
Ph-V-
Hz
380~415,50,3
380~415,50,3
380~415,50,3
Operating Frequency
Hz
45~360
45~360
45~360
Crankcase
W
40～80
40～80
40～80
Refrigerant Oil
ml
2300(FVC68D)
2300(FVC68D)
2300(FVC68D)
Outdoor Fan
Motor
Model
YDK750-6A
YDK750-6A
YDK750-6A
Type
AC FAN MOTOR
AC FAN MOTOR
AC FAN MOTOR
Brand
CHANGBA
CHANGBA
CHANGBA
Quantities
3
3
3
Insulation Class
B
B
B
Safe Class
IP44
IP44
IP44
Input Power
W
760
760
760
Output Power
W
450
450
450
Rated Current
A
3.5
3.5
3.5
Capacitor
uF
15
15
15
Speed
r/min
810
810
810
Outdoor Fan
Material
Plastic
Plastic
Plastic
Type
Axial
Axial
Axial
Fan Quantity
3
3
3
Outdoor Coil
a.Number Of Row
2
2
2
