E
xcept the above parts provided,the other parts needed during installation you must
purchase.
ACCESSORIES
N
OTE:
SELECT THE BEST LOCATION
There should not be any heat source or stream
near the unit.
There should not be any obstacles blocking the
air circulation.
A place where air circulation in the room is good.
A place where drainage can be easily done.
A place where noise prevention is taken into
consideration.
Do not install the unit near the door way.
Ensure the spaces indicated by arrows from the
wall,ceiling,fence or other obstacles.
There should not be any direct sunlight. If unavoidable,
sunlight prevention should be taken into consideration.
Indoor unit
O
utdoor unit
If an awning is built over the unit to prevent
direct sunsight or rain,be careful that heat
radiation from the condenser is not obstructed.
There should not be any animal or plant which
could be affected by hot air discharged.
Keep the spaces indicated by arrow from wall
ceiling, fence or other obstacles.
Do not place any obstacles which may cause
a short circuit of the discharged air.
Anchor the outdoor unit with a bolt and nut φ10 or
φ8 tightly and horizontally on a concrete or rigid mount.
Settlement of outdoor unit
NOTE: The outdoor unit you purchase may be like one
of the following. Install the outdoor unit according to the
dimension as indicated in the table below:
INSTALLATION
15cm
15cm
Above
Above
Above 30cm
A
L
eft installation feet
Right installation f eet
Air inlet
Outdoor Unit
Air outlet
P
acking list of the indoor unit
Packing list of the ou tdoor unit
NO. Name Unit
Quantity
1
2
3
4
5
Indoor unit
Remote controller
Instructions
Batteries
Drain pipe
Set
PC
PC
PC
PC
1
1
1
2
1
N
O. Name Unit
Quantity
1
2
3
Outdoor unit
Plastic strap
Set
ROLL
1
1
4
P
ipe protect ion ring
Luting (putty)
PC
PACKET
1
1
49
A (mm) B (mm )
Model
(WxDxH)
Ou
tdoor U nit Size of
Shape (mm )
9
12
18
24
800 X 315 X 545
540
730 X 285 X 545
730 X 285 X 545
280
540 280
545 315
900 X 350 X 700
632 352
