12 Attach the wiring harness to the burner control (see Figure 18). Attach the gas control valve molex
connector (see Figure 19).
Figure 18
Figure 19
13 Attach the blue and white wires to the IPI/CPI switch (see Figure 20). Connect the wiring harness to
the stepper motor (see Figure 21).
Figure 20
Figure 21
14 Attach the wiring harness to the comfort control valve connection (see Figure 22).
Figure 22
