Avantree Oasis Plus - Listening with a Soundbar (Bypass Function)

EN
17
RX
Bypass
TX
OFF
User Manual
OASIS PLUS
STEP 1
Slide to the “TX / BYPASS” or "OFF" position.
STEP 2
Plug an additional optical or 3.5mm AUX cable into the
correlating audio port in the transmitter’s “RX OUTPUT TO
SPEAKER” section.
STEP 3
Plug the other end into your external sound system, then
you’re good to go.
Listening with a Soundbar
The Oasis Plus’s pass-through function allows you to listen
through both headphones and an external soundbar / stereo
AVR simultaneously.
NOTE: Bypass only works with the same type of input / output, i.e.
if you connect to your TV via OPT, you’ll need to connect to your speaker
via OPT as well.
B
DC IN
AUX AUX
OPTICAL OPTICAL
RX Output TX Input
TV/Audio Source
Sound System
Oasis Plus
TRANSMITTER MODE
