Avantree Opera - Charging Headphones & Powering Transmitter; Option 1: Charging Headphones via Dock

Connecting to Your TV
Once the transmitter is connected to power source, you can then connect it to TV’s audio
output ports. You can choose one of 3 dierent ways to do this:
1. Optical port (recommended) - plug the provided optical audio cable (Figure E) into the
TV’s optical OUT or “OPT / OUT” port, then plug the other end into the transmitter’s optical
port in the “INPUT FROM TV” section.
On your transmitter, switch the "AUDIO INPUT SELECTOR" to the "OPT" position.
2. AUX 3.5mm port - plug the provided AUX 3.5mm audio cable (Figure F) into the TV’s
AUX 3.5mm output port, then plug the other end into the transmitter’s AUX 3.5mm input
port in the “INPUT FROM TV” section.
On your transmitter, switch the "AUDIO INPUT SELECTOR" to the "AUX" position.
OPERA
Quick Start Guide
8
EN
LOCK
AUX
AUX
DC IN
OPT
OPT
MIC
AUX
OPT
MIC
Input From TV Bypass Output To Speaker
E
OPT
Input From TV
OPT/OUT
TV
MIC
AUX
OPT
3. RCA port - connect the provided RCA adapter (Figure G) to the AUX 3.5mm audio
cable (Figure F). Plug the red & white RCA connectors into the TV’s “AUDIO OUT” ports,
then plug the other end into the transmitter’s AUX 3.5mm input port in the “INPUT FROM
TV” section.
On your transmitter, switch the "AUDIO INPUT SELECTOR" to the "AUX" position.
OPERA
Quick Start Guide
9
EN
LOCK
AUX
AUX
DC IN
OPT
OPT
MIC
AUX
OPT
MIC
Input From TV Bypass Output To Speaker
Input From TV
AUX
AUX 3.5mm
TV
MIC
OPT
AUX
LOCK
AUX
AUX
DC IN
OPT
OPT
MIC
AUX
OPT
MIC
Input From TV Bypass Output To Speaker
Input From TV
AUX
AUDIO OUT
TV
MIC
OPT
AUX
