Avantree Shift - Connecting Transmitter 1 via AUX or RCA

AUX
AUX
AUX 3.5mm
Input
From TV
Plug the provided AUX 3.5mm audio cable into the TV’s AUX 3.5mm output
port, then plug the other end into the transmitter’s AUX 3.5mm port in the
“INPUT FROM TV” section.
OPTION 2 - AUX 3.5mm port
Connect the provided RCA adapter to the AUX 3.5mm audio cable. Plug the
red & white RCA connectors into the TV’s “AUDIO OUT” ports, then plug the
other end into the transmitter’s AUX 3.5mm port in the “INPUT FROM TV”
section.
OPTION 3 - RCA port
AUX
AUDIO OUT
AUX
Input
From TV
10
EN
SHIFT
User Manual
