Name Description
Important:
You must enable the traps
(NotificationControlEnable) to receive a power
usage trap.
PoweredDeviceDetectType Lets you set the power detection type that the switch
uses to detect a request for power from a device
connected to all ports on the switch:
• 802.3at - IEEE standard for higher PoE (PoE+)
• 802.3at and legacy support -standard in use prior
to IEEE 802.at
Important:
The default setting is 802.3at and legacy
support. Ensure that this setting matches the
setting for the detection type used by the
powered devices on this switch.
PowerPresent Specifies the currently used power source. Available
power sources are AC and DC.
A value of acOnly indicates that the only power
supply is AC. A value of dcOnly indicates that the
only power supply is DC. A values of acDc indicates
that there are two power supplies; both AC and DC
are supplying power.
Viewing PoE information for switch ports using EDM
Use this procedure to display the PoE configuration for switch ports.
Procedure
1. In the navigation tree, click Power Management.
2. In the Power Management tree, click PoE.
3. In the work area, click the PoE Ports tab.
PoE tab field descriptions
The following table describes the fields on the PoE Ports tab.
Viewing PoE information for switch ports using EDM
July 2015 Getting Started with Avaya ERS 3500 Series 149
Comments on this document? infodev@avaya.com
