AVCOM PSA-2500C User Manual

Revision 001 SNG-2500C User’s Guide 4-1
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
S PECIFICATIONS 4
pecifications are based on Avcom control system and
graphical user interface and may vary depending on the
control system used. Please contact Avcom for specifications
based on the selected platform. Specifications are subject to change.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Frequency Coverage: 5 - 2500 MHz
Span Width: 0 - 1300 MHz
Resolution Bandwidth: 10kHz, 100kHz, 300kHz, 1MHz
RF Sensitivity: Greater than - 85 dBm Typical
Reference Levels: Selectable - 10, -30 & - 50 dBm
Scale: 5 dB/Div & 2dB/Div
Dynamic Range: 40 dB on Application Window
Amplitude Accuracy: +/- 1 dB typical
Frequency Accuracy: +/- 1kHz typical
Input Connector: “BNC” Type (others available)
Size: Width, Height, Depth 8.0” X 4.75” X 16.5”
Weight: 5 Lbs.
Power Requirements: +15 Volts DC, 3 Amps
Display: Full VGA Color LCD
Input Option: 2 standard, 4 or 6 optional
Connector Option: BNC is standard; F, N, SMA, TNC are
optional
