23
ITEM PART Nº DESCRIPTION QTY SPARES
1 07003-00099
1
/
4
BONDED SEAL
12
2 07001-00394 HANDLE PLUG 1 2
3 07340-00329 NYLON BUFFER 1 -
4 07003-00034 BACK UP RING 1 1
5 07003-00036 'O' RING 1 1
6 07003-00015 'O' RING 1 1
7 07003-00035 BACK UP RING 1 1
8 07340-00324 SPRING 1 1
9 07344-00301 PISTON 1 -
10 07004-00019
CIRCLIP 1 1
11 07003-00033
2BA BONDED SEAL
11
12 07340-00700 ADAPTOR ASSEMBLY 1 -
13 07003-00036 'O' RING 1 1
14 07003-00034 BACK UP RING 1 1
15 07340-00701 ADAPTOR 1 1
16 07340-00204 FACING WASHER 1 -
17 07340-00415 CYLINDER COVER 1 -
18 07340-00500 PISTON ASSEMBLY 1 -
19 07340-00505 PISTON ROD 1 -
20 07340-00506 BUFFER 1 -
21 07340-00510 BUFFER WASHER 1 -
22 07003-00038 AIR
PISTON CUP 1 -
23 07340-00502 PISTON WASHER 1 -
24 07002-00011 PISTON ROD NUT 1 1
25 07003-00031 PLUG 'O' RING 1 1
26 07340-00230 INTERNAL CIRCLIP 1 1
27 07391-00201 PLUG 1 -
28 07005-00041
DOUBLE MALE CONNECTOR
1-
29 07340-00417 VALVE PLUNGER 1 -
30 07340-00414 FILTER 1 1
31 07007-00016 LOCATING PIN 1 -
32 07340-00208 TRIGGER CAM LEVER 1 -
33 07340-00217 BACK UP RING 2 2
34 07001-00393
SOCKET BUTTON HEAD SCREW
3
/
8
LG
44
35 07340-04900 TRIGGER ASSEMBLY 1 -
36 07007-00439 GROOVED PIN 1 1
37 07001-00114 10-24 X
1
/
4
SKT BUT HD SCREW 1 2
38 07003-00032 ADAPTOR 'O' RING 1 1
39 07330-01302 FILTER 1 1
40 07340-00413 VALVE 1 -
41 07003-00040 'O' RING 1 2
42 07340-00416 VALVE OPERATING ROD 1 1
43 07005-00015
1
/
4
B.S.P. WASHER 1 -
44 07007-00014 CAM LEVER PIN 1 1
45 07340-00300 HANDLE ASSEMBLY 1 -
46 07340-00302 HANDLE MACHINED 1 -
47 07344-00400
JAW SPREADER HOUSING. ASSY.
1-
48 07340-00330 WIPER WASHER 1 1
49 07340-00400 CYLINDER ASSEMBLY 1 -
50 07003-00065
1
/
4
B.S.P.F. WASHER 1 1
51 07340-00407 CYLINDER MACHINED 1 -
52 07340-04600 TRIGGER GUARD 1 -
53 07003-00029
DIRT EXCLUDER
11
54 07340-00334 STEM CATCHER ADAPTOR 1 -
55 07340-00342 PINTAIL DEFLECTOR 1 2
56 07340-00332 END CAP 1 -
57 07340-00412
1
/
4
B.S.P.F. FEMALE ADAPTOR 1 -
58 07340-00401 VALVE SPRING 1 -
59 07340-00403 SPRING 1 1
ITEM PART Nº DESCRIPTION QTY SPARES
07340-00200 PARTS LIST
