P
R I M I N G
28
Priming is ALWAYS necessary after the tool has been dismantled and prior to operating. It may also be necessary to restore the full stroke
after considerable use, when the stroke may be reduced and rivets are not fully placed by one operation of the trigger.
O I L D E T A I L S
The recommended oil for priming is Hyspin VG32 available in 0.5l (part number 07992-00002) or one gallon containers (part number
07992-00006). Please find specific table and safety data below.
ENVIRONMENT
WASTE DISPOSAL: Through authorised contractor to a
licenced site. May be incinerated.
Used product may be sent for reclamation.
SPILLAGE: Prevent entry into drains, sewers and water courses.
Soak up with absorbent material.
HANDLING
Wear eye protection, impervious gloves (e.g. of PVC) and a
plastic apron. Use in well ventilated area.
STORAGE
No special precautions.
PROPERTIES RESULT
Foaming tendency/stability
ml @ 24°C Trace/Nil
ml @ 93.5°C 20/Nil
ml @ 24°C after test @ 93.5°C Trace/Nil
Air release value minutes to
0.2% air content @ 50°C4
Seal compatability index 10
Water separation time
in minutes to 40-40-0 @54°C15
@83°C15
H Y S P I N V G 32 O I L S A F E T Y D A T A
FIRST AID
SKIN: Wash thoroughly with soap and water as soon as
possible. Casual contact requires no immediate attention.
Short term contact requires no immediate attention.
INGESTION: Seek medical attention immediately.
DO NOT induce vomiting.
EYES: Irrigate immediately with water for several minutes.
Although NOT a primary irritant, minor irritation may occur
following contact.
FIRE
Suitable extinguishing media: CO2, dry powder, foam or
water fog. DO NOT use water jets.
PROPERTIES RESULT
ISO oil type HL
ISO viscosity grade 32
Kinematic viscosity
cS @ 40°C32
@ 100°C 5.3
Relative density at 20°C 0.875
Viscosity Index 95
Pour point °C- 30
Open Flash point °C 232
Neutralisation value mg KOH/g 1.5
P R O C E D U R E
I M P O R T A N T
CONNECT AIR SUPPLY (this causes the piston to bottom, allowing more priming oil into the tool).
DO NOT OPERATE THE TRIGGER WHILE THE BLEED SCREW IS REMOVED.
All operations should be carried out on a clean bench, with clean hands in a clean area.
Ensure that the priming pump is free from foreign matter
and that the oil is perfectly clean and free from air bubbles.
Care MUST be taken at all times, to ensure that no foreign matter enters the tool, or serious damage may result.
The use of a priming kit is necessary to implement the priming procedure. Ensure you select the correct kit to suit your tool model.
The part number of the kit to be used with the 07340/4/7/8 model is 07900-03401. For the 07345 and 07346 the part number
is 07900-03421.
07900-00013
1
/
8
" A/F ALLEN KEY 1
07900-00078
5
/
32
" A/F ALLEN KEY 1
07900-00192 PRIMING PUMP ASSEMBLY 1
07900-00638 PRIMING SPACER 1
ITEM PART Nº DESCRIPTION Nº OFF
7340, 4, 7, 8 PRIMING KIT
07900-00013
1
/
8
" A/F ALLEN KEY 1
07900-00078
5
/
32
" A/F ALLEN KEY 1
07900-00192 PRIMING PUMP ASSEMBLY 1
07900-00638 PRIMING SPACER 1
07340-00306 NOSE CASING 1
ITEM PART Nº DESCRIPTION Nº OFF
7345 & 7346 PRIMING KIT
