F A U L T D I A G N O S I S T A B L E
30
F
A U L T D I A G N O S I S
SYMPTOM
Several pulls required
to set rivet
Jaws will not grip rivet
stem
Jaws will not release
spent rivet stem.
Spent rivet stem is
jamming in tool.
Slow stroking tool
POSSIBLE CAUSE
➝ Low air pressure.
➝ Lack of lubrication.
➝ Worn or broken jaws.
➝ Oil level in tool low or air in oil.
➝ Worn or dirty jaws.
➝ Worn or dirty jaws.
➝ Jaw housing loose.
➝ Weak or broken nose assembly spring.
➝ Incorrect nose equipment fitted.
➝ Bent jaw spreader assembly tube preventing it from
moving forward into jaw housing.
➝ Dirty jaws or jaw housing.
➝ Jaw housing, nose tip or nose casing not properly seated.
➝ Weak or broken spring around jaw spreader assembly.
➝ Tool overprimed.
➝ Incorrect jaw spreader fitted.
➝ Bent or dirty jaw spreader assembly tube.
➝ Collector bottle too full.
➝ On 07347 tools, valve adjusting screw 69
➝ out of adjustment.
➝ Lack of lubrication.
REMEDY
➝ Increase air pressure.
➝ Lubricate tool at air inlet point.
➝ New jaws.
➝ Prime tool. (see page 29)
➝ Clean jaws.
➝ Clean or renew as necessary.
➝ Tighten against nylon locking ring.
➝ Replace spring.
➝ Replace as necessary.
➝ Replace jaw spreader assembly.
➝ Clean.
➝ Tighten nose equipment.
➝ New spring.
➝ Reprime.
➝ Replace by correct part.
➝ Renew or clean as applicable.
➝ Empty and ensure bottle never exceeds half full.
➝ Adjust.
➝ Lubricate tool at air inlet.
