Item numbers in text refer to the nose assemblies pages 12 to 15. Item numbers in bold refer to the general assembly and parts
lists pages 22 to 27.
First remove the complete nose assembly off the tool.
Insert priming spacer into the nose casing, ensuring that the spacer sits at the bottom.
Fit the nose casing to the tool.
Fill the priming pump with priming oil.
Using a vice with a soft jaw place tool at a 45° incline.
Remove bleed screw 2 and sealing washer 1 from the bottom of the handle with allen key* .
Screw priming pump into lower handle bleed screw port, complete with oil seal.
Remove upper bleed screw 37 and sealing washer 11 from the handle using
1
/8” allen key*.
Pump oil through the tool until non-aerated oil flows freely from the bleed screw port.
Fit bleed screw 37 and sealing washer 11, paying particular attention to the sealing washer which, if worn or damaged MUST be
replaced.
Remove priming pump and fit lower bleed screw 2 and sealing washer 1, checking washer - as above.
Remove the tool from the vice.
Remove the priming spacer from the nose casing and fit the nose casing to the tool.
Lay the tool horizontal on the bench with bleed screw 37 uppermost.
Remove bleed screw 37 and allow excess oil to flow out.
Replace bleed screw 37.
Remove nose casing and priming spacer.
Fit nose assembly.
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
* refers to items included in the Avdel service kit. For complete list see page 18.
