25
ITEM PART Nº DESCRIPTION QTY SPARES
1 07003-00099
1
/4 BONDED SEAL 1 2
2 07001-00394 HANDLE PLUG 1 2
3 07340-00329
NYLON BUFFER 1 -
4 07003-00034 BACK UP RING 1 1
5 07003-00036 'O' RING 1 1
6 07003-00015 'O' RING 1 1
7 07003-00035
BACK UP RING 1 1
8 07340-00324 SPRING 1 1
9 07344-00301 PISTON 1 -
10 07004-00019 CIRCLIP 1 1
11 07003-00033 2BA BONDED SEAL 1 1
12 07340-00700 ADAPTOR ASSEMBLY 1-
13 07003-00036 'O' RING 1 -
14 07003-00034 BACK UP RING 1 1
15 07340-00701 ADAPTOR 1 1
16 07340-00204 FACING WASHER 1 -
17 07340-00415 CYLINDER COVER 1 -
18 07340-00500
PISTON ASSEMBLY 1 -
19 07340-00505 PISTON ROD 1 -
20 07340-00506 BUFFER 1 -
21 07340-00510 BUFFER WASHER 1 -
22 07003-00038 AIR PISTON CUP 1 -
23 07340-00502
PISTON WASHER 1 -
24 07002-00011 PISTON ROD NUT 1 1
25 07003-00031 PLUG 'O' RING 1 1
26 07340-00230 INTERNAL CIRCLIP 1 1
27 07391-00201 PLUG 1 -
28 07005-00041 DOUBLE MALE CONNECTOR 1 1
29 07340-00417 VALVE PLUNGER 1 -
30 07340-00414 FILTER 1 1
31 07007-00016 LOCATING PIN 1 -
32 07340-00208 TRIGGER CAM LEVER 1 -
33 07340-00217 BACK UP RING 2 2
34 07001-00393
SOCKET BUTTON HEAD SCREW
3
/ 8 LG 44
35 07340-04900 TRIGGER ASSEMBLY 1 -
36 07007-00439 GROOVED PIN 1 1
37 07001-00114 10-24 X
1
/ 4 SKT BUT HD SCREW 1 2
38 07003-00032 ADAPTOR 'O' RING 1 1
39 07330-01302 FILTER 1 1
40 07340-00413
VALVE 1 -
41 07003-00040 'O' RING 1 2
42 07340-00416 VALVE OPERATING ROD 1 1
43 07005-00015
1
/4 B.S.P. WASHER 2 -
44 07007-00014
CAM LEVER PIN 1 1
45 07347-00300 HANDLE ASSEMBLY 1 -
46 07340-00302 HANDLE - MACHINED 1 -
47 07344-00400 JAW SPREADER HOUSING ASSY 1 -
48 07340-00330 WIPER WASHER 1 1
49 07347-00400 CYLINDER ASSEMBLY 1 -
50 07005-00015
1
/4 B.S.P. WASHER 2 2
51 07340-00407 CYLINDER MACHINED 1 -
52 07340-04600 TRIGGER GUARD 1 -
53 07640-00241 STEM CATCHER BODY 1 -
54 07340-00335 STEM CATCHER END CAP 1 -
55 07347-00500 SPRING HOUSING ASSEMBLY 1 -
56 07340-00336 CLAMP WASHER 1 -
57 07003-00205 'O' RING 1 -
58 07003-00067 'O' RING 1 1
59 07347-00404 ADJUSTING SCREW RETAINER 1 -
60 07001-00005 HAMMER DRIVE SCREW 1 -
61 07347-00302 PISTON SLEEVE 1 -
62
07347-00201 CARRIER 1-
63 07002-00097
1
/ 2 - 20 UNF LOCKNUT 1 -
64 07640-00239 STEM CATCHER OUTER 1 -
65 N. D.
TUBING 3mm
I
/ D MAKE FROM 07005-0045 36cm
66 07005-00456 SERRATED NIPPLE 11
67 07347-00403 CONNECTOR MACHINED 1 -
68 07003-00022 'O' RING 1 1
69 07347-00202 VACUUM ADJUSTING SCREW 1 1
70 07347-00402 CONNECTOR BOLT 1 -
71 07347-00401 FILTER (.465 DIAMETER ) 1 1
72 07347-00403 SPRING 1 1
73 07340-00401 VALVE SPRING 1 -
ITEM PART Nº DESCRIPTION QTY SPARES
07347-00200 PARTS LIST
