15
Step 12: Adjusting the seat position and angle
To change the angle and horizontal position of the seat:
Step 13: Adjusting the display and handlebar.
Seat Adjustment Bolt
B.Move the seat backward or forward and tilt to adjust the angle. The seat position horizontal to flat ground is desirable for
most riders. Do not exceed the limit markings on the seat rail, which show the minimum and maximum horizontal movement
allowed.
C.While holding the seat in the desired position, use a 6mm allen key to tighten the seat angle adjustment bolt securely to
the recommended torque value.
A.Use a 6mm Allen wrench to loosen the seat adjustment bolt on the clamp positioned immediately underneath the seat,
above the rear wheel. Do not completely remove the bold.
A. Stand in front of the bike and clamp front wheel with both legs, adjusting handle bar angle to make sure
the bike is straight in line.
