AVer PTC500 - Page 51

46
Setting menu
Sub menu
2nd sub menu
Note
Tracking Setting
(Student mode)
Tracking
Select shielded zone (8
grid) set
Preview
Define the shield zone.
Shield zone is area that
you don’t want to detect
motion.
Save
+
Press + to add the new
area
-
Press - to eliminate the
existed area.
Front side student
height(0 px)
To assure the close up
screen consistency
Rear side student
height (0px)
Camera position of lost
target preset 1
Image switch mode
tracking mode (default)
User can see the PTZ
tracking procedures.
Panoramic mode
The tracking screen will
be directly transferred
from panoramic view to
close up view
Motion sensitivity
0-7(low to high)
Overtime
35s to 280s
The time which the PTZ
go back to panoramic
view after lock the target.
Advanced Correction
Installation Height
2.0m~3.0 (10 levels)
default is 2.4
Angle Compensation
-5 degrees ~+5 degrees
(100 levels) default is 0
Preset Setting
Save preset
Call preset
ADDR (Gray out)
1
Baud rate (Gray out)
9600
Baud rate speed
adjustment
