AVer VB342+ - Advanced Remote Functions; Call and Brightness Control

5
Name
Function
3. Smart faming
One-click automatic FOV adjustment to fit all participants.
Press on the remote for 1 second can switch the Smart
framing function between auto and manual mode; a message (as
figure shown) will display on the screen to indicate in auto or
manual mode.
[Note] While in conferencing meeting, participants must face the
camera for face detection (Smart Framing).
4. Phone in
Press it to enable the phone in mode.
5. Zoom in/Zoom out
Increase/Decrease the camera zoom.
6. Preset
 To save the camera at the desired position, press and hold the
preset button until the "saved message" is displayed on the
PTZApp video screen or other video apps. Select preset
position button 0 to 9 to save.
 Press “preset” + “preset position button” (0 ~ 9) will move the
camera to the saved position.
7. Preset position
 Preset position button is used in conjunction with the Preset
button to save positions. There are a total of 0 to 9 saves.
 Press preset button and then press 0~9 to go to the saved
position.
 Press button on remote controller for 1 second can turn
on or off the WDR function.
 Press button on remote controller for 1 second to enable
Audio Tracking function.
 Press button on remote controller for 1 second to enable
Audio frame function.
 Press button on remote controller for 1 second to enable
Audio Preset Tracking function.
8. Brightness -
Decrease the brightness.
9. Call/answer*
Answer a call or start a call.
10. Enter**
Not supported.
11. Mute/Unmute
Mute/Unmute the speakerphone.
12. Volume up/down
Adjust volume up or down.
13. Preset Hotkey
Press it can move to preset position as user has set.
Auto Framing
Manual Framing
