AVer VB342+ - Wall Mount Installation

9
Wall Mount Installation
1. Please refer to the following drilling dimension for drilling the wall mount holes.
500.0mm
28.5mm
2. Drill 2 holes on the wall and screw the screws into the holes. Leave some space between wall and
screws for hanging the VB342+ on the wall.
