19
ENEN
WIRELESS ALARM KIT
H - TECHNICAL AND LEGAL INFORMATION
Operating temperature and
humidity
0°C to 40°C, 20% to 85% RH non-condensing
Storage temperature and
humidity
-10°C to 60°C, 0% to 90% RH non-condensing
Dimensions & Weight of the
Detector
75 mm x 37 mm x 16 mm / 30 g (with battery)
Dimensions & Weight of the
magnet
56 mm x 12 mm x 15 mm / 13 g
Infrared movement detector
Power supply 4.5V D/C by 3 AAA batteries (included)
Transmission frequency
433MHz
Transmission range Up to 100 m in open air
Installation height
2.2 m
Angle of detection 110°
Range of detection
8 m
Battery life 6 to 12 months, depending on use
Operating temperature and
humidity
0°C to 40°C, 20% to 85% RH, non-condensing
For indoor use only
Storage temperature and
humidity
-10°C to 60°C, 0% to 90% RH, non-condensing
Dimensions
105 mm x 64 mm x 68 mm (with wall mounting bracket)
Weight 99 g (with batteries)
