System Overview 1-3
FUNCTIONAL OVERVIEW
The Avidyne DFC100 autopilot supports the following functions:
• Flight Director
• Heading Capture/Hold
• NAV Tracking
• Vectors Mode
• VNAV Tracking
• Approach Mode (includes LOC, ILS, VOR, BC, LPV,
LNAV/VNAV, LNAV+V)
• Altitude Hold
• Altitude Capture
• Vertical Speed Hold
• Indicated Airspeed Mode
• Straight and Level
• Pilot Selectable Intercept Angles
• Control Wheel Steering (not available in all aircraft)
• Takeoff/Go Around (TO/GA) Mode (not available in all
aircraft)
• Speed-based Envelope Protection
• Full-time Envelope Alerting
NOTE
Envelope Protection vs. Envelope Alerting
There is a distinction between Envelope Protection
and Full-time Envelope Alerting. Envelope
Protection will result in active driving of the flight
control surfaces by the autopilot. Full-time
Envelope Alerting will only provide visual and aural
alerting but it is up to the pilot to manually make any
control surface changes.
